8 Channel Audio Mixer Console 48V Phantom w USB Bluetooth

Specifications

Maximum input level - MIC +24dBu Line +24dBu

Maximum output level - XLR +26dBu TRS +20dBu

Master meters - 10 segment-24dB to CLIP

Channel meters - 1 LED signal indication

Frequency response 20Hz to 30KHz 0.5dB

CMRR (MIC 1kHz)->75dB

THD+N-<0.01%(Channel to mix out)

Crosstalk at 1kHz-Fader shutoff>85dB -Mute shutoff>85dB

Noise，rms 22Hz to 22KHz-EIN -122dBu Residual output noise <-90dBu

MONO EQ-LF，shelving，+/-15dB，12KHz

HM，peak/dip，+/-15dB，2.5KH

LF，shelving，+/-15dB，80Hz

Mono channelm XLR balanced, pin 2 hot, 2K ohm, Sensitivity -60 to +10 dBu

TRS balanced, tip hot, 10K ohm, Sensitivity -40 to +10 dBu

XLR,phantom +48V

2-track return-RCA, unbalanced，4K ohm，-2 dBu

2-track send-RCA.unbalanced,<75 ohm，-2 dBu

L/R output-XLR balanced,pin 2 hot,<75 ohm，+4 dBu，Max.+22 dBu

FX/AUX output-TRS unbalanced, tip hot, <75 ohm，-2 dBu，Max.+18 dBu

Headphones-TRS，tip L,ring R，30 to 600 ohm headphones recommended

Max.Power input power-15watts

Dimension (L x W x H) 44.5*42*10.2CM

Effect Delay/Repeat

About this item

Multi Devices Compatibility : USB/Flash Reader /MP3 or Bluetooth device are very easy to connect this mixer to Mix & record; Built in built in controls provide friendly experience to play/pause, skip tracks and switch between modes

Bluetooth Wireless Audio Streaming : Cable free music streaming ability directly to the consoles; Mix all kinds of devices as smart phone to this audio mixer. Very easy to wirelessly stream all music tunes to the mixing board from Spotify or Pandora

Ultra-thin and Rugged Chassis: With only 1.4 inches thin design, sealed rotary controls to resist dust, great experience of touching to use this mixer. This compact mixer provides total dynamic control, is great for high quality on stage performance,premium quality crystal clear studio level quality audio playback

MIC + Line Inputs : Supporting XLR and unbalanced 1/4" plug with +48V phantom buttons, highly accurate LED peak level indicator,10-Segment Stereo Output Level METER and ultra musical 3 band EQ on all channels; Ultra low noise, high headroom mixer with super easy functionality for professional vocal and instrumental sound

This analog mixer provides accurate, crisp and clear sound quality. The extra clean sounding effect makes it ideal for live mix in occasions like live gigs, shows, stage performance, DJ events, and karaoke.【If there's any problem, please don't hesitate to contact us, we are very happy to help and strive for good customer service.
